Gearless Direct Drive Gauge

Gearless Direct Drive Gauge


Accuracy ±0.5% Grade 2A (6000+ = 0.5% upscale, 1% downscale)
Ambient Limits ABS: -65°F/190°F​
GFN/Metal: -65°F/400°F​
Process Limits ABS: -65°F/250°F​
GFN/Metal: -65°F/600°F​
Process Limits with Diaphragm Seal -60°F/400°F (Direct Mount)*​
-110°F/750°F (Remote Mount or Cooling Tower)​
*Exact Limits depend on diaphragm seal and fill fluids.
Wetted Materials Tube: Inconel X-750, Silver Brazed​
Socket: 316SS ​
Lens Standard: Plastic (Acrylic)​
Optional: Tempered Safety Glass​
Other Materials Case: ABS, Stainless Steel, Aluminum, or GFN​
Dial: Stainless Steel​
Case-to-Socket: O-Ring
Fillable No
Restrictor Screw Yes, removable.
Maximum Working Pressure Stable = 100%
Momentary = 150% (up to 5,000psi)
